Feelworld FW568 PRO 6" HDMI monitor with 1200nits brightness

Ultra light weight and a very bright screen
The Feelworld FW568 PRO 6’ HDMI monitor with 1200nits brightness offers you a compact 6 inch monitor with an impressive brightness of 1200cd/m². Thanks to its high resolution of 1920 x 1080, you will see every detail sharp and clear even in bright sunlight. This monitor supports HDMI input and output up to 4K60, allowing you to work effortlessly with the latest DSLRs and system cameras.


Highlights

1920 x 1080 display
Up to DCI 4K HDMI input and HDMI output
Custom 3D LUT import via SD card slot
High brightness of 1200cd/m²

Flexible connection options
With both HDMI inputs and outputs, you can easily integrate the FW568 PRO into your set up. Connect a wireless transmitter, a larger control monitor or additional equipment without fuss. The 3.5mm jack output lets you listen directly to the audio signal coming in via HDMI, ideal for quick audio control on location.


Smart tools for image control
While shooting, you have direct access to professional features such as waveform, vector scope, histogram and an anamorphic preview. The simple menu wheel at the top of the screen lets you quickly browse through all the tools. The clear tabs allow you to adjust settings without interrupting your workflow. In the LUT tab, you can also easily select and view your log profiles.


Always powered, wherever you are
The FW568 PRO effortlessly adapts to your power needs. Connect a 12V DC cable, use a USB C power bank or work with a Sony L series battery. You can also power your camera via the DC output, allowing you to keep filming longer without constantly changing batteries.


Easy mounting, flexible rotation
Whether you are working from a rig, gimbal or directly on a camera cage; thanks to the two 1/4" 20 mounting points, you mount this monitor exactly how you want. With the included hot shoe mount, you can also tilt and rotate the monitor, giving you extra freedom in every shot.


Quickly switch between settings
Working on different projects or switching between shooting settings often? The FW568 PRO offers four separate user profiles, so you can quickly recall your favourite settings without reconfiguring everything every time.


color editing directly on set
With support for 3D LUTs, you get an instant view of your final color correction. The monitor has 4 standard DE log LUTs on board, and you can load up to 32 custom LUT files (cube) via a USB stick and the included USB A to USB C adapter. So you're always working in the right style, even before you start post processing.


Carefree working in bright light
The included sun visor easily clips onto the front of the monitor. This reduces annoying reflections and keeps your vision sharp even on sunny days.


Quick control while filming
There are several physical buttons on top of the monitor, including three programmable hotkeys. This allows you to set and activate your most important functions at the touch of a button, saving you time while filming or shooting and keeping you fully focused on your image.,

Model: FW568 PRO
Screen size: 6’ IPS
Resolution: 1920x1080 pixels
Pixel Pitch: 0.069 (H) × 0.069 (V) mm
Aspect Ratio: 16:9
Brightness: 1200cd/sqm
Contrast Ratio: 1000:1
Backlight: LED
Viewing angle: 80 ° / 80 ° (L / R) 80 ° / 80 ° (U / D)
USB C L series/LP E6 power supply
8.4 VDC 2.1mm cylindrical output power
2 year warranty
,

1 × monitor
1 × HDMI cable
1 × Micro HDMI cable
1 × Sunshade
1 × Mini flash shoe holder + Allen key
1 × USB A to USB C adapter
1 × Cable management binder
1 × User guide
